Chains for Forklift

Forklift Chain - The life of lift chains on forklifts could be prolonged completely with correct care and maintenance. Like for example, correct lubrication is the most effective method in order to prolong the service capability of this part. It is essential to apply oil periodically with a brush or whatever lube application tool. The frequency and volume of oil application has to be sufficient in order to stop whatever rust discoloration of oil within the joints. This reddish brown discoloration normally signals that the lift chains have not been correctly lubricated. If this particular condition has occurred, it is very essential to lubricate the lift chains immediately.

It is common for several metal to metal contact to take place during lift chain operation. This can lead to parts to wear out in the end. The industry standard considers a lift chain to be worn out if 3% elongation has occurred. To be able to stop the scary possibility of a disastrous lift chain failure from occurring, the manufacturer greatly recommends that the lift chain be replaced before it reaches three percent elongation. The lift chain gets longer because of progressive joint wear which elongates the chain pitch. This elongation can be measured by placing a certain number of pitches under tension.

In order to ensure correct lift chain maintenance, another factor to consider is to check the clevis pins on the lift chain for signs of wearing. Lift chains are put together so that the clevis pins have their tapered faces lined up with each other. Normally, rotation of the clevis pins is commonly caused by shock loading. Shock loading takes place when the chain is loose and then all of a sudden a load is applied. This causes the chain to go through a shock as it 'snaps' under the load tension. With no proper lubrication, in this situation, the pins can rotate in the chain's link. If this particular scenario occurs, the lift chains must be replaced immediately. It is essential to always replace the lift chains in pairs to ensure even wear.


Click to Download the pdf
