Drive Axle Forklift

Forklift Drive Axle - The piece of equipment which is elastically affixed to the frame of the vehicle utilizing a lift mast is the forklift drive axle. The lift mast attaches to the drive axle and can be inclined, by no less than one tilting cylinder, round the drive axle's axial centerline. Forward bearing components combined with rear bearing elements of a torque bearing system are responsible for fastening the vehicle and the drive axle framework. The drive axle could be pivoted around a swiveling axis oriented horizontally and transversely in the vicinity of the back bearing components. The lift mast is likewise capable of being inclined relative to the drive axle. The tilting cylinder is affixed to the vehicle frame and the lift mast in an articulated fashion. This enables the tilting cylinder to be oriented nearly parallel to a plane extending from the axial centerline and to the swiveling axis.

Unit H40, H45 and H35 forklifts, which are produced by Linde AG in Aschaffenburg, Germany, have a connected lift mast tilt on the vehicle framework itself. The drive axle is elastically connected to the framework of the forklift by numerous various bearings. The drive axle contains a tubular axle body together with extension arms attached to it and extend backwards. This particular kind of drive axle is elastically connected to the vehicle framework utilizing back bearing elements on the extension arms along with frontward bearing devices situated on the axle body. There are two rear and two front bearing devices. Each one is separated in the transverse direction of the forklift from the other bearing machine in its respective pair.

The braking and drive torques of the drive axle on tis particular model of forklift are sustained using the extension arms through the rear bearing parts on the frame. The forces generated by the lift mast and the load being carried are transmitted into the floor or street by the vehicle framework through the front bearing components of the drive axle. It is important to be sure the parts of the drive axle are configured in a firm enough way in order to maintain stability of the forklift truck. The bearing parts can lessen small road surface irregularities or bumps all through travel to a limited extent and provide a bit smoother function.
