Forklift Starters and Alternators

Forklift Starters and Alternators - The starter motor of today is typically either a series-parallel wound direct current electric motor which has a starter solenoid, that is similar to a relay mounted on it, or it could be a permanent-magnet composition. As soon as current from the starting battery is applied to the solenoid, basically through a key-operated switch, the solenoid engages a lever which pushes out the drive pinion that is situated on the driveshaft and meshes the pinion using the starter ring gear that is found on the engine flywheel.

The solenoid closes the high-current contacts for the starter motor, which begins to turn. When the engine starts, the key operated switch is opened and a spring in the solenoid assembly pulls the pinion gear away from the ring gear. This action causes the starter motor to stop. The starter's pinion is clutched to its driveshaft by means of an overrunning clutch. This allows the pinion to transmit drive in just a single direction. Drive is transmitted in this way through the pinion to the flywheel ring gear. The pinion remains engaged, like for example because the driver fails to release the key when the engine starts or if there is a short and the solenoid remains engaged. This causes the pinion to spin independently of its driveshaft.

This above mentioned action stops the engine from driving the starter. This is an important step for the reason that this type of back drive would allow the starter to spin very fast that it would fly apart. Unless modifications were done, the sprag clutch arrangement will prevent utilizing the starter as a generator if it was made use of in the hybrid scheme discussed prior. Usually a regular starter motor is intended for intermittent utilization that will stop it being utilized as a generator.

The electrical parts are made in order to work for about thirty seconds to be able to avoid overheating. Overheating is caused by a slow dissipation of heat is because of ohmic losses. The electrical parts are meant to save weight and cost. This is truly the reason most owner's guidebooks used for automobiles suggest the operator to stop for a minimum of ten seconds after each and every 10 or 15 seconds of cranking the engine, if trying to start an engine which does not turn over right away.

The overrunning-clutch pinion was launched onto the marked during the early part of the 1960's. Previous to the 1960's, a Bendix drive was used. This drive system works on a helically cut driveshaft that consists of a starter drive pinion placed on it. Once the starter motor starts turning, the inertia of the drive pinion assembly allows it to ride forward on the helix, hence engaging with the ring gear. Once the engine starts, the backdrive caused from the ring gear allows the pinion to go beyond the rotating speed of the starter. At this moment, the drive pinion is forced back down the helical shaft and thus out of mesh with the ring gear.

The development of Bendix drive was made in the 1930's with the overrunning-clutch design referred to as the Bendix Folo-Thru drive, developed and introduced during the 1960s. The Folo-Thru drive consists of a latching mechanism together with a set of flyweights in the body of the drive unit. This was much better in view of the fact that the typical Bendix drive utilized so as to disengage from the ring once the engine fired, even though it did not stay functioning.

As soon as the starter motor is engaged and begins turning, the drive unit is forced forward on the helical shaft by inertia. It then becomes latched into the engaged position. Once the drive unit is spun at a speed higher than what is achieved by the starter motor itself, like for example it is backdriven by the running engine, and next the flyweights pull outward in a radial manner. This releases the latch and permits the overdriven drive unit to become spun out of engagement, thus unwanted starter disengagement can be avoided previous to a successful engine start.
